SPORTSMAN® XP 1000 S
THE WORLD'S BIGGEST, BADDEST ATVWe've redefined the ATV by every measure – an aggressive 55" stance elevates performance and stability; Bold 27" Duro® Powergrip tires deliver maximum grip and control; and a jaw-dropping 14" of suspension travel dominates the most unrelenting terrain.
Sportsman® XP 1000 S
- Fully-adjustable Walker Evans® Premium Shocks
- 27" Duro Powergrip Tires
- 500 lb of Rack Capacity
- 1,750 lb Towing Capacity
- 12.5" of Front Travel and 14" of Rear Travel
NOT REINFORCED … REDESIGNED
If you want to completely reinvent the ATV, you need to start at the foundation, which is exactly what we did. The entire chassis of the Sportsman XP® was developed to work in harmony with the bold performance attributes it delivers. We then complimented this rugged design with resilient components giving you the confidence to push further, work harder, and tackle the worst Mother Nature has to offer and never back down.
Looks can be deceiving, but rest assured beneath those muscular lines Polaris engineers developed an entirely new chassis – one that's bigger, bolder, and stronger than ever before. With 31% larger main-frame tubing, it was designed to be abused, stomped on, and beaten through the worst terrain and never give in.
RANGER XP FRONT DIFFERENTIAL
To develop the next generation of the world's toughest ATVs we looked to the world's most capable side-by-side and utilized the front differential and half-shafts from the RANGER XP® 1000. Delivering 15% increase in component strength and Active Decent Control, the system delivers rugged dependability with unquestioned confidence.
Some ATVs look tough, be we knew the new Sportsman XP® 1000 S had to deliver which is why we completely redesigned the transmission with 25% stronger components to work in harmony with the increase in travel, ground clearance and larger tires.
THE WORLD IS WAITING, CONQUER IT
The all-new Sportsman XP® is designed to succeed where others dare not tread. Armed with an arsenal of never-before-seen factory equipped performance attributes, it redefines capability in every way, resulting in a level confidence never before experienced with an ATV.
INDUSTRY'S FIRST 55-INCH STANCE
If you want to shatter the status quo you need do the unthinkable. Introducing the world's first 55" wide-stance ATV. Delivering a level of stability and performance never before thought possible in an ATV. Crawl your way through jagged rocks, navigate deep rutted trails, and straighten a twisted wooded path with uncanny accuracy.
AGGRESSIVE 27" TIRES
The impressive wide-stance of the all-new Sportsman XP® 1000 S is enhanced with 27" Duro Powergrip tires. Rugged construction resists punctures and a unique tread pattern is engineered for maximum grip in varied terrain.
TOWERING 14.5" CLEARANCE
The world knows no limits when it comes to terrain, which is why we rose above the expected and developed an ATV delivering a terrain shattering 14.5' of ground clearance. Combined with the wide, stable stance and long-travel suspension, little can stand in the way between you and destinations unknown.
MORE TRAVEL WITH MORE CONTROL
Experience a new level of ride and handling beyond expectations. The all-new Sportsman XP® 1000 S delivers a series of industry-first designs including a new long-travel suspension system that crushes terrain with uncanny smoothness, precise control, and confidence unmatched.
14" OF LONG TRAVEL
The science of suspension travel can be complicated – the new breed of ATV destroys traditional thinking with a new long-travel design that delivers everything good and eliminates the bad. The all-new Sportsman XP® 1000 S virtually eliminates the evil effects of wheel scrub, the unwanted trait of the wheels moving outward while traveling through the 12.5"/14" (F/R) of suspension travel. The result is a level of control never before experienced on an ATV.
WALKER EVANS® 2" SHOCKS
Anyone can talk about big suspension travel numbers, but all that movement is worthless without control. The new Sportsman XP® 1000 S is outfitted with Walker Evans® 2" shocks, complete with compression adjustment and dual coil springs for unrivaled ride and handling.
The Polaris exclusive ProSteer design features a dual pitman arm and draglink setup. This system virtually eliminates bumpsteer during suspension events, and minimizes the feedback to the handlebars.
ENGINEERED TO DELIVER
We set out to completely redesign the ATV, we wanted to do more than simply exceed expectations, we wanted to shatter them. With nearly unheard of towing, hauling and storage capabilities others can't match, your only limit is your imagination.
UNRIVALED RACK CAPACITY
No matter where your outdoor spirit leads you, our new high-capacity racks can bring along whatever life's adventures may need. With a front capacity of 200 lb and a rear rack capacity of 300 lb, the combined 500 lb cargo shatters the industry standard.
No matter how you measure hard work, the new Sportsman XP®1000 S measures up beyond the expected. With the ability to tow up to 1,750 lb it can move mountains of work, so you don't have to.
CAPACITY & CONVENIENCE
If you want something done right, you need to have the right tools for the job. The new Sportsman XP® 1000 S comes equipped with a standard 2" receive hitch so you can tow big loads with confidence.
ENGINE & DRIVETRAIN
|Engine Type||ProStar SOHC 4-Stroke Twin Cylinder|
|Cylinders-Displacement (cc)||952 cc / 89 HP|
|Fuel System||Electronic Fuel Injection|
|Transmission/Final Drive||Automatic PVT P/R/N/L/H; Shaft|
|Drive System Type||On-Demand True AWD/2WD|
|Front Suspension||Sealed Dual A-Arm 29.5 cm Travel|
|Rear Suspension||Sealed Dual A-Arms Rolled IRS, 35.6 cm Travel|
|Front/Rear Brakes||Single Lever 4-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake|
|Parking Brake||Park in Transmission/Lockable Hand Lever|
Tires / Wheels
|Front Tyres||27 x 9 Duro PowerGrip V2|
|Rear Tyres||27 x 11 Duro PowerGrip V2|
|Bed Box Dimensions (L x W x H)||N/A|
|Front/Rear Rack or Box Capacity||91 kg / 136 kg|
|Fuel Capacity||19.9 L|
|Ground Clearance||36.8 cm|
|Overall Vehicle Size (L x W x H)||209.5 x 140 x 125.7 cm|
|Estimated Dry Weight||400 kg|
|Seat Height||94 cm|
|Cargo System||Lock & Ride, 15 L Front Dry Storage 8 L Rear Storage|
|Hitch Towing Rating||794 kg|
|Hitch/Type||Standard / 5 cm Receiver|
|Instrumentation||All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet|
