RZR® 570

COMPACT PUNCH
45 HORSEPOWER
The ProStar® 570 engine has been specifically engineered to deliver optimum horsepower, torque, and acceleration for 50" trails. The intelligent design allows the ProStar to pounce with instant corner-to-corner acceleration, yet deliver maximum fuel-efficiency for all-day range.

COMPACT PUNCH
DEVOUR ROCKS & RUTS
Conquer harsh trails with 9" of true suspension travel. Traverse stumps and rocks with 10.5" of ground clearance and avoid others with the instant response of our 50" trail-width chassis design.

CORNER CONTROL
Our 50" chassis is more than just compact in stance. Our vehicles combine a lightweight design, refined suspension geometry, and the industry's best True On-Demand All-Wheel Drive (AWD) system for instantaneous delivery of power to the wheels that need it most. The result is unmatched control and agility across any terrain and the tightest trails.

THE DRIVING FORCE IN OFF-ROAD
MAKE IT YOUR RZR
With over 1.6 million combinations of RZR accessories, your dream RZR is just waiting to be built. Whatever your style, however you ride, you can find the right set of accessories to create your own signature look and one-of-a-kind RZR.
ENGINE & DRIVETRAIN
Engine Type | ProStar 570 4-Stroke DOHC Single Cylinder |
Cylinders-Displacement (cc) | 567 cc / 45 HP |
Fuel System | Electronic Fuel Injection |
Transmission/Final Drive | Automatic PVT P/R/N/L/H; Shaft |
Drive System Type | On-Demand True AWD/2WD |
Cooling | Liquid |
Suspension
Front Suspension | Dual A-Arm with Stabilizer Bar 22.9 cm Travel |
Rear Suspension | Dual A-Arm with Stabilizer Bar 22.9 cm Travel |
Brakes
Front/Rear Brakes | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
Parking Brake | Park in Transmission |
Tires / Wheels
Front Tires | 25 x 8-12; Ancla |
Rear Tires | 25 x 10-12; Ancla |
Wheels | Stamped Steel |
DIMENSIONS
Bed Box Dimensions (L x W x H) | 51 x 102 x 23 cm |
Front/Rear Rack or Box Capacity | N/A kg / 136 kg |
Fuel Capacity | 27.4 L |
Ground Clearance | 26.7 cm |
Overall Vehicle Size (L x W x H) | 273 x 127 x 175.2 cm |
Wheelbase | 196 cm |
Estimated Dry Weight | 452 kg |
Features
Cargo System | Lock & Ride |
Hitch Towing Rating | 680.4 kg |
Hitch/Type | Standard 3.2 cm Receiver |
Instrumentation | Single Analog Dial with 5 cm LCD Rider Information Center, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Volt Meter, Service Indicator and Codes, Seatbelt Reminder Light, DC Outlet |
Variants | Off-road |
